BOTTOM PLAYFIELD ASSEMBLY - PARTS LIST, CONTID.PART NO. AE47-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
0360-00929-0100 WIRE FORM: ROLLOVER ...RIGHT
14 AE47-00049-0000 WIRE ACTUATOR ASSY. - RIGHT
0360-00134-0000 BRKT. : ROLLOVER WIRE - RIGHT
OE47-00123-0000 WIRE FORM: ROLLOVER - RIGHT
15 A360-00217-0000 WIRE ACTUATOR ASSY.
0360-00135-0000 BRKT. : ROLLOVER WIRE - LEFT
0360-00931-0000 WIRE FORM: BALL RETURN
16 A360-00230-0000 SWITCH & BRKT. ASSY. SLINGSHOT (2 REQ '0. )
A360-00069-0000 SWITCH ASSY.
17 A360-00239-0000 SWITCH & DIODE ASSY. SLINGSHOT (5 REQ'O.)
-
A360-00069-0000 SWITCH ASSY.
18 A360-00239-0100 SWITCH~ BRKT. , & DIODE ASSY. (3 REO to. )
A360-00069-0000 SWITCH ASSY.
19 A360-00241-0000 SWITCH & DIODE ASSY.
A360-00055-0000 S\HTCH ASSY.
20 A365-R0300-B113 SWITCH W/TARGET. BRKT •• DIODE & CAP ASSY. (6 REQ '0.)
A365-R0300-0003 SWITCH & TARGET ASSY.
0360-00103-0000 BRKT. : SlHTCH --
21 A365-00035-0000 S~IITCH, DIODE & PLATE ASSY. (5 REO 10. )
A360-00061-0000 SW ITCH ASSY.
22 A365-00035-0100 SWITCH. DIODE & PLATE ASSY. W/CAP
A360-00061-0000 SWITCH ASSY.
23 A365-00036-0000 SWITCH~ DIODE & PLATE ASSY. EJECT HOLE
A967-00075-0000 SWITCH ASSY.
3 . 1 1
