BOTTOM PLAYFIELD ASSEMBLY - PARTS LISTPART NO. AE47-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AC70-0022-0100 FLIPPER ASSY. SINGLE SWITCH RIGHT (SEE COMMON ASSY.)
.-
A365-00045-0000 FLIPPER BREAK SWITCH ASSY.
2 AC70-00022-0200 FLIPPER ASSY. SINGLE SWITCH LEFT (SEE COMMON ASSY.)
A365-00045-0000 FLIPPER BREAK SWITCH ASSY.
3 AE47-00005-0000 PLAYFIELD CABLE ASSY.
4 AE47-00018-0000 BALL CHANNEL ASSY. (SEE COMMON ASSY.)
5 AE47-00023-0000 DROP TARGET ASSY. SINGLE IN-LINE W/MEMORY (SEE COMMON ASSY.)
A£47-00014-0000 PLUNGER & LINK ASSY.
A967-00066-0000 SWITCH & DIODE ASSY.
6 AE47-00028-0000 DROP TARGET ASSY. SINGLE (SEE COMMON ASSY.)
1\967-00066-0000 SWITCH & DIODE ASSY.
7 AE47-00029-0000 DROP TARGET ASSY. 3 IN-LINE W/MEMORY (SEE COMMON ASSY.)
AE47-00034-0000 MEMORY - COIL ASSY.
AE47-00013-00XF PLUNGER & STRIKER ASSY.
A370-00086-0000 SWITCH & DIODE ASSY.
8 AE47-00033-0000 EJECT HOLE (SAUCER) ASSY. (SEE COMON ASSY.)
9 A967-00053-0100 THUMPER BUMPER ASSY. (3 REQ'D.) (SEE COMMON ASSY.)
10 A967-00059-0000 SLINGSHOT KICKER COIL ASSY. (2 REQ'D.) (SEE COMMON ASSY.)
11 1\360-00235-0000 KNOCKER ASSY. (SEE COMMON ASSY.)
12 1\331-00042-0000 WIRE ACTUATOR ASSY.
0360-00135-0000 BRKT. : ROLLOVER WIRE - LEFT
0360-00929-0200 WIRE FORM: ROLLOVER - LEFT
13 A360-00215-0000 WIRE ACTUATOR ASSY. RIGHT (2 REQ'D.)
0360-00134-0000 BRKT. : ROLLOVER WIRE - RIGHT
3 .10
