GAME STATUS DISPLAYS (Continued)
Adjustment
Informatlon--Ad
At end of the Audit Information presentation, with the AUTO-UP switch in the Up position, the operator
can press the ADVANCE button to proceed to the Adjustment Information portion of the
WI};JO!J'~WOIro@]
Game Status Displays, as shown in the Player Score Displays. A list of the Game Adjustments appears in
the
WI};JO!J'~WOIro@]
Game Adjustment
Table.
The operator can press the ADVANCE button ~to view each Adjustment Information display item. To
proceed more rapidly through this information, the operator only has to press
and hold
the ADVANCE
button. If a desired item is passed, the operator can use the MANUAL-DOWN switch position with the
ADVANCE button to back up to the desired item.
The
WI};J~I1I1wt1Irot§)
Game Adjustment
Table lists the 70 items of the Adjustment Information portion of
the Whirlwind Game Status Displays. Presentation of the displays is similar to that for the Audit
Information (that is, the upper display shows a descriptive phrase; the light type below the column
headings names the respective backbox displays where the information appears, etc.).
The
WI};J~I1Ilw~Iro@]
Game-specific Adjustmenta Table lists those game-specific Adjustment items for
which settings vary between the major models of pinball products. The Game Adjustment Table, along
with the Game-specific Adjustments Table, provides the Factory Settings for the three major models of
pinball products (defined by country/language designation).
NOTE
In these tables, each Adjustment Item's Factory Setting for each of the three major
models of pinball products is that shown in the 'Domestic' (US / Can.) column, unless a
superseding entry appears in the French or West German columns of these tables. A
superseding entry takes precedence over the 'Domestic' entry for the only the
particular model indicated.
\WJIIilOrrOwOI1\l@]
Game-specific Adjustments Table
Adjustment
Descriptive Phra&
Factory Setti
Item
Domestic
(Lower)
WGer/
(Lower)
(Upper Display)
(US/Can.)
French European
Ad 31
MAX. REPLAY BOOST
1 Million
47
BLOWER SPEED
ON
48
NORMAL FLASHERS
NORMAL
51
GRAND H. S. T. D.
ON
52
GRANDCREDITS
2
4
3
