A-16361 Bridge Diverter Assembly
0 _
Imm
part Number
1.
A-16496
2.
A-10S21
3.
01-S413
4.
AE-26-1200
5.
02-4731
6.
10-437
7.
20-8716-5
S.
12-7082
9.
03-7066
10.
20-8712-43
11.
4010-0100S-06
12.
4701-00004-00
13.
4700-00132-00
Description
Bracket Assembly
Flipper Stop Bracket Assy.
Coil Mounting Bracket
Coil Assembly
Solenoid Plunger
Spring Kicker
Roll Pin. 1/8 x
7/16"
Lg.
Actuator
Coil Tubing
"E" Retaining Ring
Mach. Screw. 10-32 x 3/S P-PH
Lockwasher.#10 Split
Flatwasher.
5/64
x 7/16 x 2Sga.
Twilight Zone 2-26
