8-12665 Kicker Arm (Slingshot) Assembly
,
,
, ,
...•
, , , ,
<,
,
,
, ,
,
....
"
,
,
, ,, ,
, ,,
.....
<;
<;
,
..••.
,
,
.....
..••.
Associated Parts for Right
&
Left Kickers:
Item
Part
Number
pescriptlon
Item
part
Number
Description
1.
12-6227
Hairpin Clip
6.
A-16645-R
Coil & Bracket Assy., Right
2.
A-12664
Kicker Crank Assembly
A-16645-L
Coil & Bracket Assy., Left
3.
A-5653
Mounting Bracket Assembly
a) B-7572-1
Bracket & Stop Assembly
4.
4700-00030-00 Flatwasher, 17/64 x 1/2 x 15ga.
b) 01-8-508-S
Coil Retaining Bracket
5.
A-51 03
Coil Plunger Assembly
c) 4006-01 0 17~06 Mach. Screw, 6-32 x 3/8
a) 02-2364
Coil Plunger
d)
4406-01119-00
Nut, 6-32 ESN
b) 03-8085
Armature Link
e) AE-27-1200
Coil Assembly
c) 20-8716-5
Roll Pin, 1/8 x 7/16"
f) 03-7066
Coil Tubing
7.
10-128
Spring
~
Twilight Zone 2-24
