Page 118 - Twilight Zone (Bally)

A-16313 Rear Diverter Assembly
14
3
Item Part Number Description Item Part Number Description
1. 01-11210 Bracket, Rear Diverter 9. A-14185 Drive Arm Assembly
2. A-10821 Flipper Stop Bracket 10. 20-8712-43 "E" Ring, 7/16" Shaft
3. AE-26-1500 Coil Assembly 11. 4010-01082-04 Set Screw, 10-32 x 114" SH
4. 01-8413 Mounting Coil Bracket 12. 20-8790 Nyliner Bearing
5. 03-7066 Coil Tubing 13. 20-8712-25 "E" Ring, 1/4" Shaft
6. A-13278 Plunger Assembly 14. 4701-00004-00 Lockwasher, #10 Split
7. A-16316 Diverter & Shaft Assembly 15. 4010-01008-06 Mach. Screw, 10-32 x 3/8" P-PH
8. 10-135 Spring '---.---'
Twilight Zone 2-28
