A-16132 Gumboil Machine Assembly
Item Part Number
Description
1.
03-8813
Base, Front
:.._,__v-
....
2.
03-8814
Base, Rear
3.
03-8816
Globe, Front
4.
03-8817
Globe, Rear
5.
03-8821
Cap
6.
02-4718
Shaft
7.
03-8818
Separator
8.
03-8820
Gear, Driven
9.
03-8819
Handle
10.
03-8815
Bearing
11.
03-8847
Drive Adapter
12.
03-8475
Wheel, Geneva
13.
03-8476
Wheel, Drive
14.
01-11073
Bracket, Motor & Drive
15.
14-7984
Motor,12V
16.
4106-01013-06
SMS #6 x
3/8
P-PH Type 25 (5 used)
17.
4700-00090-00
Flatwasher #6
18.
5647-12693-08
Sub-Miniature Switch
19.
4002-01105-07
MS, 2-56 x
7/16
P-PH SEMS (2 used)
20.
01-8240
Nut Plate, 2-56
21.
20-8712-25
"E"-Ring,
1/4"
Shaft (3 used)
22.
4106-01013-10
SMS #6 x
5/8
P-PH Type 25 (2 used)
23.
H-16616
Cable, Gumball Motor
24.
4008-01017-10
MS, 8-32 x
5/8
PH-RH SEMS (4 used)
25.
4700-00091-00
Flatwasher,
11132
x
7/8d
x 15ga.
Not Shown:
26.
03-8887
Blade Guide
--.....-
..
/
27.
H-16610
Cable, Gumball Switch
28.
5070-09054-00
Diode, 1N4004
Twilight Zone 2-30
