GENIE TARGET ASSEMBLY
The Genie Target consists of a hinged metal bracket which holds switches and a flasher. A molded
Genie is attached to this assembly by #8 screws (2). A ball in play will strike the Genie causing the
switches to close and score. The whole assembly can be easily dismantled for adjustment or flasher
replacement.
Molded Genie
lI8
scr ews
(2)
Mo.in
REMOVE THE MOLDED GENIE
To remove the Molded Genie, slide the playfield out of the cabinet and remove the #8 screws (2) on the
back of the Genie. Then gently lift up the Genie and remove it from the metal base. The switches and
flasher can now be serviced.
118 Screws
I
V"he"
--------~--- -- ---
--------%---- -
Switches
Side View
1-51
