"SHOOTING STAR" SPIKE ASSEMBLY
The Spike's can save a ball from exiting play. A ball rolling over the spikes will be detected by an opto
pair. When a ball is detected, the coil will drive the Spike finger assembly up and capture the ball in play.
The Spikes will automatically lower and give the ball back to the player.
Upper Opto ArM
Lower Opto
Lift
Coil
Sp ike Cage
REMOVE THE SPIKE ASSEMBLIES
To remove the Spike Assembly. first disconnect the upper opto cable (1) under the playfield, then remove
the #8 machine screw (2) that holds the upper arm in place. Then gently lift the arm (3) and remove it
from the playfield. Remaining screws (4) that hold the main Spike assembly, can be taken out to lower
the Spike Assembly.
(1) Disconnec t cable
(3) ReMo veUpper ArM Assy
Play field
Screws
(2) ReMove
"8 Screw
-:
(4) ReMove screws nnd lower
Side View
