ADJUSTMENTS
Open the coin door, press the Enter button and the System Menu appears on the screen. Use the Up
and Down buttons to move the cursor and select the Adjustment menu. Press the Enter button to open
the menu when it is selected. Once the Adjustment menu is open, use the Up and Down buttons to move
the cursor and select a sub-menu. Press the Enter button to enable the sub-menu and view the next
level of functions.
Use the Up and Down buttons to move the cursor and select a sub-menu function. Press the Enter
button to enable that function. Use the Up and Down buttons to change the value. Press the Enter
button to lock in the new value, or press the Escape button to retain the original value and return to the
sub-menu. The setting values are color coded: Blue
=
Factory Setting; Red
=
Changed Value; Green
(during adjustment)
=
Default Factory Setting
Press the Escape button to return to the sub-menu. Press the Escape button a second time to return to
the Adjustment menu and a third time to return to the System Menu.
SYSTEM MENU
XXIXX/XXXX
X:XXp.m.
Read Test Report
Dialnosttcs
fii ••
,m;""
Bookkeeping
Utilities
Printouts
Language
Reset Machine
Feature Adjustment
Game Pricing
Score Awards
Extra Balls
Match
High Scores
Audio Adjustments
Clock/Format
Communication
ADJUSTMENT MENU
XXlXXIXXXX
X:XX p.m.
System Adjustments
SYSTEM ADJUSTMENTS
Power Saver
The Power Saver feature helps to prolong the life of each lamp by reducing the power of
all the lamps when the game is idle. This adjustment leads to sub-menus to choose
from.
Lamp Power Saver
This adjusts the number of minutes of idle time (no game being played) before
the Lamp Power Saver mode is enabled.
Settings:
Off,1 to 60 minutes
Factory Setting: 15
1-18
