AUDIO TESTS CONTINUED •.•
Stop Audio Test
Selecting this item stops the music started from the above tests.
VIDEO TESTS
The Video Tests lead to a menu of tests for the video circuits.
Color Bars
The Color Bars test fills the screen with several shades of colors to help with red, green,
and blue color level adjustments. Each color should appear sharp and clear.
Convergence Grid
The Convergence Grid test fills the screen with a series of lines and dots. The imagines
should be clear and the dots should be round.
RGBTests
The RGB tests fill the screen with red, green, or blue. Press the Up or Down buttons to
change the colors.
Setup Tests
The Setup test allows for all aspects of the monitor picture adjustment at one time.
Alignment Tests
This test allows for picture object alignment.
DEVICE TESTS
The Device Tests lead to a menu of test for specific mechanisms on the playfield.
Empty Balls
This function kicks out all the balls loaded in troughs, lockups, poppers, and kick-outs
until no balls remain in those locations.
As the trough kicks out balls, they will stack up in the shooter lane, which may require
manual clearing in order to allow further balls to be kicked out.
FUSE CHECK
This test shows the status - good or blown - of the fuses on the Power Driver board. A layout of
the fuses on the Power Driver board is displayed on the screen. The good fuses are shown in
green, the blown fuses are shown in red.
DIP SWITCH
This test shows the current DIP switch setting, as well as the available DIP switch setting for
various countries. Press the Up or Down buttons to cycle through the countries that have DIP
switch settings available.
CHECKSUM ROMS
This test automatically checks the checksums for the ROMs. Press the Enter button and wait until
all the ROMs have been checked.
Note: This can take
a
while to complete.
1-17
