PLUG IN THE CABLES
10. Do not force cables onto connectors, they should plug in easily.
Plug the cables into the proper
connectors on the Joining Bracket, which is located on the right side of the rectangular opening in the
rear of the cabinet (see Figure 11). Secure the OB25 , and OB09 cables in place using the
thumbscrews.
Reach through thq_,rectangular opening and pull the ground strap up. You may need to wrap the
ground strap through the round hole to take up some slack. Remove the wing nut from the stud
located to the left of the rectangle opening. Slip the ground strap ring terminal over the ring lug and
secure it in place with the wing nut.
Rectangular Opening
Detail of Joining Bracket
1,
O""h
0
J.
••
Top View
SpeakerCable DB25Cable DB09 Cable
12fJV
IsolationCable
Ground Strap
Joining Bracket
Side View
FIGURE 11
11. Replace and lock the backbox rear door. Replacing the screws is optional.
12. Lean the playfield against the cabinet front and plug the cables back into the rear bracket.
13. Carefully, lift the playfield from the front and tip the back of it onto the slides. Slide it back into the
cabinet. Be sure that the cables at the back of the playfield are not kinked.
14. Rest the front of the playfield on the top of the cabinet as you did in Step 2. Open the coin door.
Lower the playfield all the way into the cabinet.
15. Be sure the required number of balls is installed.
16. Replace the playfield glass. Be sure that the PINBALL 2000 logo is in the lower left comer. See
Figure 12 below. Snap the front molding securely into place. Close and lock the coin door.
AGURE12
1-6
