3. Firmly grasp the playfield and slide it forward (toward you) along the bottom track slide brackets.
Rotate the front of the playfield down and set it on the floor as shown in Figures 3 through 5.
FIGURE 3
FIGURE 4
Unplug Cables from Playfield Panel.
/
AGURE5
4. Unplug the cables from the bracket on the back of the playfield and pull the playfield away. See
Figure 5, above.
5. The leg levelers, nuts, and leg botts are among the parts in the cash box. Install a leg leveler and nut
on each of the front and rear legs. Place the cabinet on a support. Using two leg bolts in each leg
attach the front and rear legs to the cabinet. Screw the levelers all the way into the legs. Remove the
cabinet from the support. See Figure 6, below.
---=:II
----=:II
Leg Assembly
AGURE6
1-3
