10. Verify that the
required number
of balls are installed in the game. This game uses 4 balls.
11. Install playfield mylars if desired.
NOTE: The Scared StiffT
M
playfield is coated with a special hardcoat surface and does not require a
protective mylar. However, mylars can be purchased through your
local
Bally Distributor. Specify
part number 03-9600-1 for the full playfield mylar.
12. Clean and reinstall the playfield cover glass.
13. To attach line cord, remove envelope stapled to the inside cabinet (near cashbox). Remove the four
Phillips-head screws that mount the
line
cord cover plate to the rear cabinet. Match the prongs on
the plug with the holes in the receptacle and push line cord securely into place. Make sure cord
aligns with the indentation of plate (indentation should point toward bottom of cabinet). Remount line
cord cover plate. If desired, tamper resistant screws are provided in an envelope marked "Security
Screws" (located in cashbox) to remount cover plate.
.
14. Move the game into the desired location; recheck the level and pitch angle of the playfield.
15. If a padlock is desired, install the security bar as shown below.
Hasp Slapls Brld.
01·14086
16. IMPORTANT:
Fill out and return the registration card.
1-4
