4. Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked or
pinched. Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position. Unlock the backbox and remove the
backglass, storing it carefully to avoid damage. Remove the shipping screws holding the insert
panel. Unlatch and open the insert panel. Carefully lift the speaker panel and lay it down on the
playfield glass. Be careful not to damage the Dot Matrix Display/Driver Board. This allows access to
the bolt holes used for securing the backbox upright. Install the washer-head mounting bolts through
the bottom holes of the backbox into the threaded fasteners in the cabinet to secure the backbox.
Close the insert panel and latch it into position. Replace the speaker panel. Reinstall the backglass
and lock the backbox.
1&1
CAUTION
FAILURE
TO
INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect. Always lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or damage and
possible personal injury.
6. Extend each leg leveler slightly below the leg bottom, so that all four foot pads protrude
approximately the same distance. Remove the cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Move the front molding latch lever toward the left side of the game,
to release the front molding. Lift the front molding off the playfield cover glass, return the latch lever
to the right, and close the coin door. Carefully slide the glass downward, until it clears the grooves of
the left and right side moldings. Lift the glass up and away from the game, storing It carefully to avoid
breakage.
B.
Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper playfield
level (side-to-side). NOTE: These measurements must be made ON the playfield, not the cabinet
nor the playfield cover glass. Tighten the nut on each leg leveler shaft to maintain this setting.
9. The TRU-PITCHTMlevel is located on the right shooter rail. This allows the playfield pitch angle to be
accurately adjusted WITHOUT REMOVING THE GLASS. The first line (closest to the front of the
game) on the level is approximately 6 degrees. Every line thereafter is approximately another
1/2
degree of pitch. The recommended pitch is 6
1/2
degrees. The nose of the bubble should be
between the first and second line on the level (see diagram below).
T'<U -PlfC H'"ieve l 6 1/ 2 deg rees
A- ' 5 8 02- P
CAUTION
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside the cabinet. The
plumb bob weight is among the parts in the cash box; the operator should install the weight and adjust
this tilt mechanism for proper operation, after completion of the desired playfield pitch angle setting.
The unit is factory installed for
a
6
112degree angle. If an adjustment is necessary, loosen screw at
the bottom of the unit. Move the pointer, one groove at
a
time to the left or right, depending on the
degree desired. Hold pointer in place and tighten screw.
1-3
