CAUTION
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside the cabinet. The
plumb bob weight is among the parts in the cash box; the operator should install the weight and adjust
this tilt mechanism for proper operation, after completion of the desired playfield pitch angle setting.
The unit is factory installed for
a
6
112degree angle. If an adjustment is necessary, loosen screw at the
bottom of the unit. Move the pointer, one groove at
a
time to the left or right, depending on the degree
desired. Hold pointer in place and tighten screw.
11. Install the left and right vault doors (backbox side panels). Attach one vault door bracket to each door,
using the tamper resistant screws found in the same box as the vault doors and brackets. Attach the
vault doors to the backbox with the decal side of the door facing the front of the game.
VaultOOor Brtrt.
01-14345
left
Vault
Door
A·20937·2
8-32 X
%
Tamper Resistant
Screws
40011-01093-128 (20)
----
o
o
Right Vault Door
~7.1
12. Install the backbox header if desired. Hardware and header brackets are located in the unique parts
bag.
Screened Header
31-2565
11-32X 3/8· Screw (4)
40011-01015-06
13. Verify that the
required number
of balls are installed in the game. This game uses 4 balls.
14. Install playfield mylars if desired.
15. Clean and reinstall the playfield cover glass.
1-4
