16. To attach line cord, remove envelope stapled to the inside cabinet (near cashbox). Remove the four
Phillips-head screws that mount the line cord cover plate to the rear cabinet. Match the prongs on
the plug with the holes in the receptacle and push line cord securely into place. Make sure cord
aligns with the indentation of plate (indentation should point toward bottom of cabinet). Remount line
cord cover plate. If desired, tamper resistant screws are provided in an envelope marked "Security
Screws" (located in cashbox) to remount cover plate.
(Po rt af ca b in et sho wn
for re fe rence only )
~
17. Move the game into the desired location; recheck the level and pitch angle of the playfield.
18. If a padlock is desired, install the security bar as shown below.
Hasp Hinge Br1d.
01-14085
Hasp Staple Brkt.
01-14086
Slotted Hasp
01-14084
19. IMPORTANT: Fill out and return the registration card.
1-5
