A-15769 Ball Popper
&
Opto Assembly
10 8
Cp
,
"
(0----
G)-----
(0-----
- ----------------
Item Part Number
Description
Item Part Number
Description
1 4106-01013-06 Sh. Metal Screw, #6 x 3/S"
S.
03-S561
Ball Popper Cup
2.
400S-0 1017 -04 Mach. Screw, S-32 x 1/4"
9.
4106-01152-06 Sh. Metal Screw, #6-32 x 3/8"
3.
AE-23-S00
Coil Assembly
10.
A-1690S
Opto LED Assembly-Fl IV
4.
10-135
Spring
11.
03-7067-5
Coil Tubing
5.
02-4668
Armature Assembly
12.
A-15914
Bracket, Ball Popper
6.
01-9794
Mounting Bracket
13.
23-6420
Rubber Grommet
7
A-16909
Opto Photo Transistor Assy.-RTV
14.
H-16229
Plfd. Opto Cable
