A-16580 Ball Popper Assembly
(1~
--~
~~I-------
Item Part Number
Description
1 01-11402
Mounting Bracket
2.
03-8561
Ball Popper Cup
3.
4106-01152-06 Sh. Metal Screw, #6 Thd.
4
01-9794
Coil Mtg. Bracket
5.
03-7067
Coil Tubing
6.
AE-26-1200
Coil Assembly
7 4008 -0 1027 -04 Mach. Screw, #8-32 x 5/16"
0 -
--- ---. 8)
I I
I
I
I
I
Item Part Number
Description
8.
4106-01013-06 Sh. Metal Screw, #6 P-DR
9.
10-135
Spring
10.
A-14585
Armature & Ext. Assembly
11.
A-16908
oprc
LED Assembly, RTV
12.
A-16909
Opto Photo Transistor Assy., RTV
13.
23-6420
Rubber Grommet
14.
H-16229
Plfd. Opto Cable
Judge Dredd 2-20
<:
