A-16802 Diverter Assembly
0
7
1~)
13
(6
17
3
...
_ - - - -- -
Item Part Number
Description
1 01-11573
Bracket
2.
AE-25-1000
Coil Assembly
3.
A-16780
Plunger Assembly
4.
01-8-508-T
Solenoid Bracket
!) .
10-437
Spring
6
4420-01119-00 Nut 1/4-20 ESN
!
4700-00033-00 Flatwasher, 17/64 x 3/4 X 21ga.
e
20-8712-25
"E"-Ring,
1/4"
Shaft
':l
4008-01017-04 Mach. Screw, 8-32 x 1/4" P-R
Item Part Number
Description
10.
20-8790
Nylined Bearing
11.
4008-01083-04 Set Screw, #8 x 1/2"
12.
23-6686
Bumper Pad - Round
13.
A-16781
Shaft Assembly
14.
A-16782
Crank Assembly
15.
03-7067-5
Coil Tubing
16.
23-6420
Rubber Grommet
17.
A-16988
Bracket Assembly
18.
4010-01006-04 Mach. Screw, 10-3:' x L·j" I)· UI; l ': I
Judge Dredd
2-22
