A-20447
Cyber Space Assembly
Item Part Number
Description
1 A-20445
Plunger Assembly
a) 01-14028
Link
b) 20-8716-17
Roll Pin
c) 02-2364
Coil Plunger
18
2 A-20446
Coil Bracket Assembly
a) 4008-01003-04 Mach. Screw, 8-32 x
1/4"
b) 01-8-508-T
Coil Retaining Bracket
4
c) 04-10212
Bracket
d) 03-7066-3
Coil Tube
e)
AE-25-1000
Coil Assembly
f)
H-19523
Mini Solenoid Cable
3 10-135
Spring
4 07-6706
Shoulder Rivet (2)
5 4406-01119-00 Nut 6-32 ESN (2)
**6 36-50042-1
Wood Panel
7 4408-01138-00 Nut 8-32 ACORN (2)
8 04-10213
Pivot Arm
9 04-10215
Cyber Space Base
10 03-9103.1-9
Rollover Button, Red (9)
11 10-503
Spring (9)
12 4700-00011-00 Flat
Washer,11/64x7/16x16ga.
*13 4008-01003-09 Mach. Screw, 8-32 x
9/16"
14 4006-01003-06 Mach. Screw, 6-32 x
3/8"
15 04-10277
PC Board
16 03-6047-1
Plastic Spacer,
1/4" (6)
17 4106-01042-12 Sh. Metal Screw, #6-32 x
3/4" (6)
18 04-10214
Cyber Space Cover
19 20-8790
Nylined Bearing (2)
20 07-6704-04
Pop Rivet,
1/8"
(4)
21 01-14105.1
Ball Guard (2)
* Not Shown.
** For Reference Only.
2-25
