A-20587
Drop Target Assembly w/Cables
Item Part Number
Description
Item Part Number
Description
A
A-14615
1-8ank Drop Target Assembly
19)
5647-12693-31
Mini Micro Switch
1)
03-8750
Target, Flush
20)
01-8600
Switch Insulator
2)
A-14617
Bracket & Post Assembly
21)
4002-011 05-12
Mach. Screw, 2-56 x
3/4"
3)
4408-01119-00
Nut #8 ESNA
22)
4402-01119-00
Nut, 2-56 ESNA
4)
A-11397
Stop Bracket Assembly
23)
A-14908
Target KlDown Assembly
5)
AE-26-1200
Coil Assembly
a) 01-8647-L
Actuator
6)
01-8413
Bracket & Coil Mounting
b) A-15821
Armature Sub-Assembly
7)
03-7066-4
Coil Tubing
c) A-14913
Frame & Eyelet Assembly
8)
A-11388-2
Plate & Reset Plate Assembly
d) 10-363
Extension Spring
9)
4700-00072-00
Flat Washer,
17/64
x
1/2
x 22ga.
e) SM1-26-600
Coil Assembly
10)
10-392
Spring - Compression
f) 4006-01003-03
Mach. Screw, 6-32 x
3/16"
11)
20-8712-25
"E"-Ring,
1/4"
Shaft
g) 4700-00089-00
Flat Washer,
11/64x7/16x16ga.
12)
01-10183
Switch Bracket
h) 4701-00003-00
Lockwasher #8 Split
13)
4006-01003-03
Mach. Screw, 6-32 x
3/16"
j)
4008-01005-06BR Mach. Screw, 8-32 x
3/8"
14)
03-8034
Stop Single Target
24)
03-8630
Actuator Guide
15)
4010-01025-14
Mach. Screw, 10-32 x
7/8"
25)
4700-00003-00
Flat Washer,
1/8
x
9/32
x 21ga.
16)
07-6688-17N
Rivet,
5/32
x
7/32"
8
H-16437
General Switch Cable
3"
17)
10-433
Spring, Extension
C
H-19693
Coil Cable
3"
18)
5070-09054-00 Diode 1N4001
2-24
