A-20500
Hand Assembly
lliun
Pad Number
DescriRtion
Item Part Numb~r
DescriRtion
1 01-14081
Y-Switch Lever
35 A-14265-13
Socket Receptacle Assembly
2 01-14094
Support Angle
36 A-20533.1
Position Encoder PC Board (2)
3 04-10282
Opto Board Bracket (2)
37 07-6704-04
Pop Rivet 1/8 x 1/4 (5)
4 01-8240
Nut Plate (2)
38 4002-01105-08 MS 2-56 x 1/2 P-PH-S (4)
5 01-11675
Fishpaper Insulator
39 4006-01168-06 MS 6-32 x 3/8 PL-HH-S
6 02-5206
X-Screw
40 4006-01168-04 MS 6-32 x 1/4 PL-HH-S (2)
7 02-5207
X-Rod
41 4006-01168-16 MS 6-32 x 1 PL-HH-S (3)
8 02-5208
Y-Screw
42 01-13752
Extension Fishpaper
9 02-5209
Y-Rod
43 4008-01168-06 MS 8-32 x 3/8 PL-HH-S (4)
10 02-5210
X-Nut
44 4008-01168-12 MS 8-32 x 3/4 PL-HH-S (5)
11 02-5211
Y-Nut
45 4406-0 1119~OO Nut 6-32 ESNA (9)
12 03-8171-9
Mini Dome, Tr Red
46 H-20469.2
Back Panel Cable Assembly
13 03-7655-4
Wire Harness Clip, 1/4" (6)
47 4008-01015-08B TT 8-32 x 1/2 P-PH
14 04-10255
Opto Wheel (2)
48 5070-09054-00 Diode, 1N4004 1.0A (2)
15 04-10230
X-Motor Bracket
49 4010-01082-04 SS 10-32 x 1/4 SH-CP (2)
16 04-10231.4
Magnet Can
50 4700-00003-00 FW .125 x .271 x .032ga. (5)
17 04-10232
Magnet Carriage
51 4008-01168-04 MS 8-32 x 1/4 PL-HH-S (2)
18 04-10233
Screened Back Panel
52 4008-01168-08 MS 8-32 x 1/2 PL-HH-S
19 04-10234.1
Y-Motor Bracket
53 31-2521-1
Back Panel Decal #1
20 04-10235
Y-Support Bracket
54 31-2521-2
Back Panel Decal #2
21 04-10236
X-Support Bracket
55 31-2521-3
Back Panel Decal #3
22 04-10237
Y-Arm
56 EI-204
Teflon Grease (as req'd)
23 04-10268
Back Panel Support Brace
57 03-9424
Molded Left Hand
24 12-7308.1
Guard Wire
58 A-20612
Hand Switch Assembly
25 14-8025
Hand Mechanism Motor (2)
59 03-9454
Nylon Tie Wrap, 4" (6)
26 20-10285
Coil Magnet/Thermal
Brkt
60 5556-13939-00 Ferrite Bead 1-1/8 x 1/4 x 1/8 (2)
27 20-10278
Coupling Body, .187
61 03-7655-8
Wire Harness Clip, 1/2"
28 20-10279
Coupling Body, .250 (3)
62 H-20689-2
Switch Cable Assembly
29 20-10280
Coupling Spider (2)
63 4008-01093-12B TR 8-32 x 3/4 PH
30 20-8712-43
"E" Retaining Ring, 7/16 (2)
64 4408-01119-00 Nut #8 ESN
31 20-8712-62
"E" Retaining Ring, 5/8 (2)
65 EI-125
Loctite 242 (1 place)
32 20-8712-12
"E" Retaining Ring, 1/8 (2)
66 04-10345
X-Motor Guard
33 24-8802
#906 Bulb, .69A 13V
67 20-10288
Tinnerman Clip, Magnet (2)
34 5647-12693-06 Mini Micro Switch (2)
Note: Balooned part numbers on drawing will appear on a future amendment.
2-26
