Solenoids/Flashers
Item Part No.
Description
01A AE-23-800
Outhole Kicker
01C #89 Flashlamp
Captive Ball Flasher
02A AE-23-800
Ball Shooter Lane Feeder
02C #89
1906
Flashlamps Cntr Ramp 1 & Bldg Flashers
03A AE-26-1200
3-Bank Drop Target Reset
03C #89 /906 Flashlamps Cntr Ramp 2 & Spinner Flashers
04A AE-23-800
CaliforniaFault
04C #906 Flashlamp
Cntr Ramp 3 Flasher
05A AE-26-1S00
Eject Hole
05C #906 Flashlamp
Cntr Ramp 4 Flasher
06A AE-24-900
Bottom Ball Popper
06C #906 Flashlamp
Right Ramp 1 Flasher
07A AE-23-800
Knocker/Ticket Dispenser (b)
07C #89/906 Flashlamps Right Ramp 2 Flasher
08A Not Used
08C #906 Flashlamp
Right Ramp 3 Flasher
09 5580-12145-01
Building Motor Relay
14-7941-1
Building Motor
10 5580-12145-01
High P'fieldGen lIIuminRelay·
11 5580-12145-01
Insert Bd Gen lIIuminRelay·
12 5580-09555-01
Solenoid AlC Select Relay··
13 AE-23-800
Top Ball Popper
14 #906 Flashlamps Jackpot
1
Sun Flashers
15 5580-12145-01
Low P'fieldGen lIIuminRelay·
16 #89/906 Flashlamps On Ramp & J Bumper Flashers
17 AE-23-800
Left Jet Bumper
18 AE~26-1500
Left Kicker ("Sling")
19 AE-23-800
Right Jet Bumper
20 AE-26-1500
Right Kicker ("Sling")
21 AE-23-800
Lower Jet Bumper
22 Not Used
FL 11630/50VDC Lower Left and Right Flipper
FL 11722150VDC Upper Left Flipper
* -
On Relay Board, C-11998-1, on Playfield and Insert Board
** -
In backbox on Aux Power Driver Bd, 0-12247
OIA
Rubber Parts
Item Part No. DescrIption Qty
Item Part No. Description
Qty
A 23-6300 5/16" Ring
10
J 23-6519-4 Lg Red Flipper Ring 3
B 23-6301 3/4" Ring
3
K 23-6535 Bumper
7
C 23-6303 1-1/4" Ring
1
L 23-6552 Sleeving, Yellow 3
D 23-6305 2" Ring
4
M 23-6556 Sleeving, Black
7
E 23-6306 2-1/2" Ring
2
N 23-6579-1 Bumper, Tapered, Wh 1
F 23-6307 3" Ring
2
P 23-6626 Grommet
3
G 23-6313-1 Grommet
1
H 23-6327 Ball Shooter Tip 1
EARTHSHAKER65
