Backbox Parts List
Item Part No.
1 01-6645
2 B-1 0686-1*
3 A-12497
4 0-12184-1
5 A-12498
6 0-11883-568*
7 01-8569
8 5100-09418-00
9 5040-09051-00
10 A-11-888
11 0-12247-568*
12 01-9047
13 0-12246*
14 20-9549
15 0-11581-568*
16 0-12313-568*
17 0-12518
a) 31-1420-568
b) 31-1422-554
c) 0-12232-1*
d) 0-12501
e) 5555-12015-00
n
5555-12068-00
Description
Venting Screen
Knocker
&
Bracket Assy
Upr Insert Bd Hinge Assy
P.C.B Plate Assy
Lwr Insert Bd Hinge Assy
System 11B CPU Board
Lwr Spkr Panel Bracket
Bridge Rectifier, 100v,35A
Capacitor, 30,000 IlFd, 25v
EARTHSHAKER,
Backbox
Aux. Pwr Oriver Board
Insert Stop Bracket
Power Supply Assembly
Cam Lock, 3/4"0 x 27/32"L
Audio Board Assembly
Backbox Interconnect Board
Oisplay/Speaker Panel Assy
Cover, OispVSpkr Panel Assy
Speaker Grill
Master Oisplay PC Board Assy
7-Lamp Speaker Panel Assy
Speaker 40, 6" Rad., 10w
Speaker 4" Piezo, SOw
* Refer to Individual Unit's Parts List
•
BACKBOX
Miscellaneous
EARTHSHAKER
Parts
A-8552-568
31-1357-568
03-7960-568
08-7028-T
20-9347
20-9518
31-1463-568
31-1470
31-1485-568
31-1486-568
Backglass Assy
Backglass,
EARTHSHAKER
Playfield Mylar
Glass-Playfield
Toggle Latch
Backbox Hinge
Orop Target Oecal Set
Start Button Oecal
Ramp Oecal Set
Top Building Oecal
567-IN
01-6571
01-6655
01-6652
31-1006-568
31-1 008-568
31-1 009-568
5795-10937-09
5795-10938-27
EARTHSHAKER ,
Insert
Hinge Mtg Bracket, Insert Board
Latch-Insert Board
Stop Bracket
Plastics Set,
EARTHSHAKER
Bottom Arch (Screened)
Shooter Plate (Screened)
Ribbon Cable, 20-Conductor, 9"
Ribbon Cable, 26-Conductor,27"
EARTHSHAKER64
