Basic HTML Version
Part No.
A·12238
A-12239
A-12558
8-12156
H-12543
01-8774
01-8795
03-6047-4
03-7520-2
03-8044-9
03-8149-9
03-8214
07-6688-17N
Part No.
A-12239
A-12506
8-12156
H-12544
01-8710
01-8774
03-8149-9
03-8149-10
03-8149-13
03-8213
Center Ramp Assembly
pIn
R-12487
Description
Sub-Mini Switch Assembly
Sub-Mini Switch Assembly
Switch Gate Assembly
Single Flash Lamp Assembly
Ramp Cable, Left
Switch Bracket
Ramp Flap
Spacer,
5/16"
Nylon, Ty-Wrap
Mini-Post (Red)
Mini Dome (Red)
Center Ramp
Rivet-Nickel Plate
Part No.
07-6688-18N
07-6688-19N
23-6535
31-1485-568-1
31-1485-568-2
4002-01005-06
4006-01027-06
4106-01004-08
4106-01004-10
4106-01004-12
4406-01128-00
4700-00003-00
4701-00024-00
Description
Rivet, 118x
3/16
Rivet,
1/8
x
7/32
Rubber Grommet
Center Ramp, Decal
Center Ramp, Decal
Mach. Screw, 2-56 x
3/8
Mach. Screw, 6-32 x
3/8
Sh Metal Screw, #6 x
1/2
Sh Metal Screw, #6 x
5/8
Sh Metal Screw, #6 x
3/4
Nut, 6-32 KEPS
Flat Washer,
1/8
x
9/32
x 21gao
Lockwasher, #2 Split
Right Ramp Assembly
pIn
0-12489
Description
Sub-Mini Switch Assembly
Switch Gate Assembly
Single Flash Lamp Assembly
Ramp Cable, Right
Ramp Flap
Switch Bracket
Mini Dome (Red)
Mini Dome (Blue)
Mini Dome (Clear)
Right Ramp
Part No.
07-6688-17N
07-6688-19N
31-1485-568-4
4002-01005-06
4006-01027-06
4106-01004-08
4406-01128-00
4700-00003-00
4701-00024-00
Description
Rivet-Nickel Plate
Rivet,
1/8
x
7/32
Right Ramp, Decal
Mach. Screw, 2-56 x 3/8
Mach. Screw, 6-32 x 3/8
Sh Metal Screw, #6 x 1/2
Nut, 6-32 KEPS
Flat Washer, 1/8 x 9/32 x 21ga.
Lockwasher, #2 Split
Spiral Ramp Assembly
pIn
0-12364
Part No.
Description
Part No.
Description
01-8997
Ramp Flap
07-6688-19A
Rivet, 1/8 x 7/32, Chrome
03-8211
Spiral Ramp-Base
31-1485-568-5
Spiral Ramp, Decal
03-8212
Spiral Ramp-Top
31-1485-568-6
Spiral Ramp Base, Decal
07-6688-17N Rivet-Nickel Plate
4700-00003-00
Flat Washer, 1/8 x 9/32 x 21gao
RIGHT RAMP ASSEMBLY
D-I2489
CENTER RAMP ASSEMBLY
R-I2487
SPIRAL RAMP ASSEMBLY
D-12364
EARTHSHAKER 63
