Upper Playfield Lamps
Lamp Location/Description
18
Big Red Bolt
20
Big Blue Bolt
25
W (in "WIN")
26
I (in "WIN")
27
N (in "WIN")
28
W (in "WAR")
29
A (in "WAR")
30
R (in "WAR")
31
JACKPOT Bolt
32
ADVANCE RANSOM Bolt
33 Motor Target Bolt 3
34
Motor Target Bolt
2
35
Motor Target Bolt
1
NOTE:
Switches
1 - 4
and
6 - 7
are on the
Speaker/Display Panel (R-A-N-S-O-M).
Item Part No.
16 5647-12073-06
17 B-8928
18 B-8928
19 B-8928
22 5647-12073-24
23 5647-12073-24
24 5647-12073-06
25 5647-12073-18
26 5647-12073-18
27 5647-12073-18
28 5647-12073-18
29 5647-12073-18
30 5647-12073-18
30 5647-12073-01
33 A-11177-1
34 A-11177-1
35 A-11315-3
36 5647-12073-22
37 5647-12073-22
38 5647-12073-22
Upper Playfield Switches
Description
. UP (Motor Targets)
Left Jet Bumper
Right Jet Bumper
Lower Jet Bumper
Loop End
1
Loop End
2
DOWN (Motor Targets)
W(in "WIN")
I (in "WIN")
N
(in "WIN")
W(in"WAR")
A (in "WAR")
R (in "WAR")
UPF Wire Ramp Entry
Upper Target
Middle Target
Lower Target
Lower Lock
Middle Lock
Upper Lock
IUatk
1uigbt 72
