Upper Playfield Parts
Item Part No.
1 B-12671
2 B-12658
3 B-12657
4 B-12693
5 D-12660
6 C-12464
a B-12465
7 12-6846
8 C-12674
9 12-6826
9A 01-9151
10 A-12640
a 12-6833
10A 12-6466-3A
1112-6831
12 B-12708
a) 12-6741
13 B-12720
a) 12-6841
14 B-9414-2
15 D-12702-R-1
16 B-12759
17 01-9168
18 12-6830
19 A-12767
Description
3-Ball Lockup Kickback
Ball Guide Assembly
Ball Guide Assembly
a-san
Lockup Wire Ramp
Ball Guide Assembly
Motorized Target Assembly
Target Motor Assembly
Wireform
Plastic Ramp Assembly
Popper Wire Ramp
Ball Guide Batfle
Bail Gate Assembly
Gate Wire
Wireform, 3/4"
Shooter Exit Wire Ramp
Ball Gate Assembly
Gate Wire
Ball Gate Assembly
Gate Wire
Jet Bumper (3)
UPF R Flipper Assembly
Ball Guide Assembly
R Hinge Post Bracket
Wire Ramp
Hinge Post Bracket Assy
Upper Playfield Solenoids/Flashers
Item Part No.
Description
01C #906 Flashlamps UPF Big Red Bolt Flasher
02C #906 Flashlamps UPF Big Blue Bolt Flasher
07A AE-23-800
3-Ball Lock Kickback
08C #906 Flashlamps 3-Ball Lock Flashers
12 5580-09555-01 Solenoid AlC Select Relay'··
17 AE-23-800
Left Jet Bumper
19 AE-23-800
Right Jet Bumper
21 AE-23-800
Lower Jet Bumper
Backbox Solenoids
(Not Shown)
09 5580-09555-01 Insert Bd Gnlilium Relay
*
14 AE-23-800
Knocker
• - On Relay Board. C-11998-1. on inside of Insert Bd
••• - On Aux Power Driver Board. D-12247
