Lower Playfield Parts
Item Part No.
Description
1 12-6842
Bottom Arch Fence
2 12-6468
Anti-Rebound Wire
3 C-11626-L-3 Lwr Left Flipper Assy
a) 20-925~6 Lg Flipper Paddle & Shaft
4 B-11873-1 Left Outlane Kickback
5 B-12743
L Flipper Return Frame
6 B-12665
Kicker Arm ("Sling") Assy
7 B-12651
Ball Guide Assembly
8 B-12639-L Left UPF Hinge Post
9 C-11223-1 3-Bank Drop Target
10 B-12650
Ball Guide Assembly
11 C-12654
Ball Guide Assembly
12 C-12655
Ball Guide Assembly
13 C-12652
Ball Guide Assembly
14 01-9122
Skyway Ramp Entry Plate
15 C-12653
Ball Guide Assembly
16 B-12636
Skyway Ramp Assembly
17 0-11335-2 Ball Popper Assembly
18 B-12599
Shooter Lane Turnaround
19 C-12656
Ball Guide Assembly
20 12-6466-6 Wireform, 1-1/2"
21 12-6466-15 Wireform, 3-3/4"
22 01-9145
Eject Hole Deflector
23 B-9361-R Eject Hole
a) 03-7351-1 Tr Red Plastic Ball Seat
24 B-12649
Ball Guide Assembly
25 B-12639-R Right UPF Hinge Post
26 12-6827
Wire Ramp
27 A-12831
Magna Save™
28 12-6466-12 Wireform, 3"
29 B-12695
R Flipper Return Frame
30 C-11626-R-3 Lwr Right Flipper Assembly
a) 20-9250-6 Lg Flipper Paddle
&
Shaft
31 C-9638
Ball Shooter Lane Feeder
(Ball Trough Parts beneath Bottom Arch)
B-8623
Upr Trough Baffle Assy
01-5575
Bottom Arch Mtg Bracket
C-8235
Lwr Trough Baffle Assy
12-6542
Baffle Wire form
01-3569-1 Ball Trough
