Parts Information
Lamp Board
(n5_cn)
pin
C-12519
Part No.
5768-12380·00
24·8767
24-8768
5070-09054-00
5791-10871·07
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25 A.)
Diode, 1N4004, 1.0 A.
Header, 7-pin s~ post
Lamp Board
("l n)
pin 8-12224
Part No.
5768-12312-00
24-8767
, 24-8768
5070-09054-00
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A.)
Diode, 1N4004, 1.0 A.
Lamp Board ("U3-C")
pin
C-12723
Part No.
5768-12419-00
24-6549
24-8757
A-10231-1
Description
Upper Playfield PC Board
Light Bulb, #44
Miniature Socket
PCB Mtg Socket
&
Bulb
Relay Board
(Sol. 11
&
16)
pin
C-11902-1
Part No.
5768-12221-00
5070-09054-00
5580-12145-00
5791-12273-02
5791-12273-07
Description
PC Board
Diode, 1N4004, 1.0 A.
Relay, 24vdc, 30 A.
Header, 2-pin sq post (J1)
Header, 7 pin sq post (J2)
o
Kl
Lamp Board (113-C")
pin 0-12503
Part No.
5768-12379-00
24-8767
24-8768
5070-09054-00
5791-10871-12
5010-09534-00
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A.)
Diode, 1N4004, 1.0 A.
Header, 12-pin sq post
Resistor,
on
Lamp Board ("5-L")
pIn 0-12520
Part No.
5768-12381-00
24-8767
24-8768
5070-09054-00
5791-10871-07
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0 A.
Header, 7-pin sq post
Lamp Board ("U4-C")
pin
C-12724
Part No.
5768-12420-00
24-6549
24-8757
A-l0231-1
Description
Upper Playfield PC Board
Light Bulb, #44
Miniature Socket
PCB Mtg Socket
&
Bulb
Relay Board
(Sol. 9 & 10 Gen. Ilium)
pin
C-11998-1
Part No.
5768-12243-00
5070-09054-00
5580-09555-01
5010-09534-00
5791-12273-02
5791-12273-07
Description
PC Board
Diode, 1N4004, 1.00 A (01)
Relay, 24vdc, 30A (K1)
Resistor,
on
(W1,W2)
Header, 2-pin sq post
(J1)
Header, 7-pin sq post
(J2)
0
-Gill-
0
Wl-c:J-
W2c_:]-
SS80-{)9SSS-
01
:::tI
r
<
o
Ch-r-=---i
SS80-1214S-{)O
(II (II
II II
v v
- N
UU
o
