Parts Information
b . I
r- - -----.,
.r c o c
00000.00000
0 II :
:
J4"""""1Jr,04IIII
1.._ ...•
....1
.10
0 0 0 0 0 .0 0 0 0
u~.
J5-
Backbox Interconnect Board
pIn 0-12313-563
Part No.
5768-12332-00
5010-09534-00
5012-12238-00
5012-12337-00
5012-10023-00
5012-12188-00
5490-10892-00
5731-09651-00
5733-12060-01
5791-10862-03
5791-10862-07
5791-10862-09
5791-10862-10
5791-10862-12
5791-10862-15
5791-10862-16
5791-10862-18
16-8850-243
Ckt Designator
W9-W13
R14, R15
R13
A5,A8
R1-R4, R6, R7
U1-U3
F1-F4
J2,J16
J9
J6
J7,J10,J20
J5,J13,J18
J8
J4,J11,J12,J19
J1,J3,J14
Description
Master Interconnect Board
Resistor, 00
Resistor, 3.3KQ, 5w, 10%
Resistor, 1.5KO, 5w, 10%
Resistor, 40, 5w, 10%
Resistor, 30, 5w, 10%
Opto Isolator 4N25
Fuse, 5A.S.B., 250v
Fuse Holder, F1-F4
Connector,3 pin Hdr Sq Pin .156
Connector, 7-pin Hdr Sq Pin .156
Connector, s-pin Hdr Sq Pin .156
Connector, 10-pin Hdr Sq Pin .156
Connector, 12-pin HdrSq Pin .156
Connector,15-pinHdr Sq Pin .156
Connector, 16-pin Hdr Sq Pin .156
Connector, 18-pin Hdr Sq Pin .156
P.C.B. 1.0. Label
Spkr/Display Lamp Bd
pIn
C-12700
Part No.
5768-12406-00
24-8767
24-8768
5070-09054-00
5791-10871-08
Description
Speaker Lamp PC Board
Twist Lamp Socket
Bulb, #555
(6.3v,
.25 A.)
Diode, 1N4004, 1.0 A.
Header, 8-pin sq post
Lamp Board
("2-C")
pIn 0-12503-1
Part No.
Description
5768-12241 -00
24-8803
24-8802
5070-09054-00
5791-10871 -02
PC Board
Twist Lamp Socket
Bulb, #906
(13v,
.69 A.)
Diode, 1N4004, 1.0 A.
Header, 2-pin sq post
