Jet Bumper Assembly
pIn
8-9414 (Above the playfield)
Item Part No.
Description
1 A-4754
Bumper Ring Assembly
2 03-6009-A5
Bumper Base, White
3 03-6035-5
Bumper Wafer, Blue
4
03-7443-5
Bumper Body, White
5 10-7
Spring
6 A-11199
Socket
&
Bulb Assembly
a) 24-8776
Lamp Socket
b) 24-8768
Bulb, #555
Not Shown 03-7444-9
Cap, Jet Bumper
Jet Bumper Coil Assembly
pIn
8-9415-1 (Beneath the playfield)
Item Part No.
Description
1 B-7417
Bracket and Stop Assembly
2 01-1747
Coil Retaining Bracket
3 01-5492
Armature Unk, Steel
4 01-5493
Armature Link, Bakelite
5 02-3406-1
Coil Plunger
6 10-326
Armature Spring
7 AE-23-8oo
Coil
8 03-7066
Coil Tubing
Jet Bumper Associated Parts
B-8928
A-7459-7
SW-11A-35
01-1168
01-3670
03-7395
4005-01051-18
4405--1117-00
5070-06258-00
5010-09036-00
5040-09370-00
Jet Bumper Switch Assy (3 used)
Switch Assembly
Switch
Mounting Bracket
Switch Plate, Curved
Switch Actuator
Mach. Screw, 5-40 x
1-1/8
Nut, 5-40 Hex
Diode, 1N4001
Resistor, tooo,
1/4w,
C.
F.
Capacitor, 22J.1fd,
16v±20"lo
Standup Target Assemblies
Item Part No.
1 8-11696-1
1 8-11696-2
1 8-11696-4
1 8-11696-5
1 8-11696-6
2 5070-06258-00
Part No.
A-6378
AE-23-8oo
03-7066
A-8335
02-2364
20-8716-5
01-4251
Description
Standup Target (8Iue)
Standup Target (Green)
Standup Target (Red)
Standup Target (White)
Standup Target (Yellow)
1N4001 Diode
jJ)
@l
fl
3
----®
@
~
-.
Outhole Kicker Assembly
pIn 8-8039-2
Description
Mounting Plate Assembly
Coil Assembly
Coil Tubing
Coil Plunger Assembly
Plunger
Roll Pin
Ball Return Unk
Part No.
Description
A-B038
4006-01003-03
A-6889
20-8712-25
03-7176-1
10-101-4
Coil Stop Assembly
Mach. Screw, 6-32
x
3/16
Kicker Lever Assembly
E-Ring Clip,
1/4"
Striker Ring
Spring, Reset
