Wireform and Ball Gate Locations
Item Part No. Description
12-6468 Anti-Rebound Wire
2 12-6842 Bottom Arch Wire Fence
3 12-6466-8 Wireform, 2~ (4 used)
4 C-13428 Left Wire Ramp
5 12-6466-12 Wireform, 3~ (3 used)
6 12-6466-16 Wireform, 4~ (2 used)
7 A-13244 Ball Gate Assembly
8 C-I3429 Right Wire Ramp
9 B-13409 Ball Gate Assembly
10 12-6466-18 Wireform, r
Under Bottom Arch:
11 A-B645 Rollover Wire & Bracket Assy.
12 A-5844-44 Roliover Wire & Bracket Assy.
13 A-5844-45 Roliover Wire & Bracket Assy.
14 12-6542 Ball Return Gate Wire
@af!tt/MIDWAY 4-6a
