Wireform, Ball Gate
&
Spin Target locations
8
ltarn Part No.
Description
1 12-6468-2
Anti-Rebound Wire, 2~
2 12-6468
Anti-Rebound Wire,
3-1/8"
3 A-13301
Ball Gale Assembly
a)
12-6912-1
Gate Wire
4 A-13301
Ball Gate Assembly
a)
12-6884-1
Gate Wire
5 A-13627-1
Switch Gate Assembly
6
8-12586
Spin Target Assembly
7 C-13925
Wire Ramp
8 12-6466-4
Wireform, 1~
9 B-13726
Switch Gate Assembly
10 B-13920
Spin Target Assembly
11 12-6466-16 Wireform,4ft
12 B-12586
Spin Target Assembly
13 12-6466-9
Wireform, 2"
14 A-13626
Ball Gate Assembly
15 12-6920
Curved Wireform
16 A-13860
Ball Gate Assembly
17 12-6914
Bent Wireform
18 B-13598
Wireform Assembly
Under Bottom Arch:
19 A-8645
Rollover Wire
&
Bracket Assy.
20
A-5844-44
Rollover Wire
&
Bracket Assy.
21 12-6857
Ball Return Gate Wire
Note: All wireforms are not shown. See pp. 4-12a and 4-16a for usage.
4-6b
