Ball Gate and Wireform Locations
1Iem Part No.
Description
12-6871
Anti-Rebound Wire
2 A-13068
Switch Gate Assy. (2 used)
3 A-8112-L
Left Ball Gate Assembly
4 12-6860
Ball Popper Wire Ramp
5 A-8244-R
Right Ball Gate Assembly
6 12-6466-10
Wireform,
2-1/2"
7 12-6867
Ball Runway Ramp
(Under Bottom Arch)
8 A-8645
Rollover Wire
&
Brkt Assy.
9
A-5844-44
Rollover Wi re
&
Brkt Assy.
10 A-5844-45
Rollover Wire
&
Brkt Assy.
11
12-6857
Ball Return Gate Wire
Note: AI! straight wireforms are not shown.
See p. 4-17 for usage.
4-6
