Wireform and Ball Gate Locations
(2009)
Item Part Number
Description
1
12 - 6871
Anti-Rebound Wire
2
12-6872-1
Actuator Wire
a)
01 - 9344
Switch Gate Bracket
(Used on Ramp C -13026)
3
A - 13288
Ball Gate Assembly
4
12 - 6864
Wire Ball Guide
5
A - 8244 - L Ball Gate Assembly
6
A -12844'
Coil Operated Gate Assembly
7
12 - 6855
Wire Ball Guide
8
A-13114
Entrance Gate Assembly
(Used on R - 12829 Ramp)
9
12 - 6854
Wire Ball Guide
10
A - 11760 - 1 Shooter Gate Assembly
11
12 - 6876
Wire Ball Guide,
2-112"
(UNDER BOTTOM ARCH)
12
A - 8645
Rollover Wire & Bracket Assembly
13
A - 5844 - 44 Rollover Wire & Bracket Assembly
14
A - 5844 - 45 Rollover Wire & Bracket Assembly
15
12 - 6857
Ball Return Gale Wire
'Used in conjunction with 8-12847 Ball Gate Actuator.
(See
p.
5-49)
