Page 320 - BallyMidway YELLOW Parts Catalog 16-9147-B

(2008)
Ball Gate, Wireform & Spin Target Locations
Item
1
2
3
4
5
6
a)
7
B
9
10
11
Part Number
12 - 6468
12 - 6466 - 10
A - 12915
A - 8244 - L
A - 12910
A - 12908
B - 12942
12 - 6466 - 8
B - 12164
12 - 6869
12 - 6466 - 12
12 - 6466 - 11
Description
Anti-Rebound Wire
Wire Ball Guide, 2-112-
Ball Gate Assembly
Ball Gate Assembly
Ball Gate Assembly
Ball Gate Assembly
Coil & Ball Gate Actuator Assembly
Wire Ball Guide, 2" (2 used)
Spin Target Assembly
Bent Wireform
Wirelorm, 3"
Wireform, 1-112"
(UNDER BonOM ARCH)
12
13
14
15
A - 8645
A - 5844 - 44
A - 5844 - 45
12 - 6857
Rollover Wire & Bracket Assembly
Rollover Wire & Bracket Assembly
Rollover Wire & Bracket Assembly
Ball Return Gate Wire
