Page 319 - BallyMidway YELLOW Parts Catalog 16-9147-B

SEO Version

Wireform, Sail Gate and Spin Target Locations
c::-
0 0 0
c: :-OO~
(2006)
Item Part Number
Description
1
12 - 6843
Anti-Rebound Wire
2
12 - 6466 - 10 Wireform, 2-1
12~
(2 used)
3
B - 12672
Wire Ramp with Switch
a)
12 - 6818
Wireform Ramp, left
4
12 - 6466 - 5 Wireform,
1-1/4"
(2 used)
5
A - 12765
Ball Gate Assembly
6
A - 8244 - L Left Ball Gate Assembly
7
B • 12623
Ball Gate Assembly (2 used)
8
A - 8244 • R Right Ball Gate Assembly
9
12 - 6825
Curved Wireform
10 12 - 6466 - 12 Wireform, 3"
11 12 - 6819
Right Wire Ramp
12 8 - 12705
Spinner Gate Assembly
(UNDER BOnOM ARCH)
13 A - 8645
14 A-5844-44
15 A-5844-45
16 12 - 6542
Rollover WiTe
&
Bracket Assembly
Rollover Wire
&.
Bracket Assembly
Rollover Wire
&
Bracket Assembly
Ball Return Gate Wire
2
