DROPTARGET ASSEMBLY: 3 SIDE-BY-SIDE (ORANGE)
PART NO. AE94-0003S-0000
..
~
1.29
FREE GATE RELAY ASSEMBLY - PARTIAL PLATE - PARTS LIST
PART NO. A365-00083-0000
ORDER BY PART NUMBER ONLY
ITEM
PART NO.
DESCRIPTION
1
0390-00702-0Xf
BALL GATE SHAfT
2
0017-00100-0120 RING RER .250 DIA.
3
A365-00084-0000 BASE PLATE
&
BEARING ASSY.
I
~
I
A390-00031-0000 HUB
&
ROLL PIN ASSY. (ITEMS 4
&
5)
4
0390-00703-00XF HUB
5
0017-00007-0066 ROLL PIN
AE34-00023-0000 "G" RELAY
&
COIL ASSY. (ITEM 6 THRU 13)
6
0017-00042-0627 ACTUATOR: SWITCH RELAY
7
A390-00030-0000 GATE BALL ACTUATOR
,
8
AE34-00022-0000 SWITCH: FREE GATE RELAY ASSY.
9
0020-00243-0000 SPRING PLATE
10
A390-00029-0000 COIL (2 LUG) POLE PIECE ASSEMBLY
11
0390-00107-00XF SPRING RETAINER
I
I
12
0010-00135-0200
I
COMPRESSION SPRING
13
0390-00106-00XF RELAY FRAME
1.44
