DROP TARGET ASSEMBLY SINGLE IN-LINE W/MEMORY
PART NO. AE47-00023-0000 BACK CABINET ~~SY. - PARTS LIST, CONTID.
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION ,
26 A365 .•00346-0000 AUXILIARY COIL BD. W/SPACERS ASSY.
I B084-91902-AOOO AUXILIARY COIL DRIVER BD. ASSY.
27 B084-91880-AOOO DUAL SOLID-STATE RELAY BD.
* AH03-00037-0000 SPEAKER ENCLOSURE ASSY. (INCLUDES ITEMS 28 THRU 42)
28 AH03 ..•00038-0000 SPEAKER CABLE ASSY.
29 AH03-00042-0000 TOP-LIGHTS JUMPER CABLE ASSY.
30 A365 ...00309-0000 LAMP SOCKET W/CONNECTOR & PINS ASSY.
31 OH03-00120-00XF RETAINER BRACKET; SPEAKER ENCLOSURE
- 32 OH03-00911-0000 LENS: SPEAKER-ENCLOSURE
33 OH03-00912-0000 LENS COVER; SPEAKER-ENCLOSURE
34 OH03-00121-00XF VENT: GRILLE
I 35 0017-00003-0615 LAMP: WATT MISEH INCANDESCENT 34 WATT I
,
36 OH03-00505-0000 BACK BOX: W/SPEAKER ENCLOSURE
* NOT PART OF BACK CABINET ASSY. & MUST BE ORDERED SEPARATELY
