BACK CABINET ASSEMBLf
ORDER BY PART NUMBER ONLY
DROP TARGET ASSEMBLY SINGLE ...PARTS LISTPART NO. AE47-00028-0000
ORDER BY PART NUt1BER ONLY
ITEM PART NO. DESCRIPTION
* AH03-00039-0000 COVER ASSY.: SPEAKER ENCL. (2 REQ 10.) (INCLUDES ITEMS 37 THRU 41)
37 0017-00003-0570 SPEAKER: 4 OHM 15 WATT 5-1/4" DIA. (2 REQ' D. )
38 OH03-00119-00XF GRILLE: SPEAKER (2 REQ'D.)
39 OH03-00504 ..•0000 COVER: SPEAKER ENCLOSURE (WOOD) (2 REQ'D.)
40 0017-00101-0137 8-32 X 16 ROUND HEAD CARRIAGE SCREW (8 REQ'D.)
41 0017-00103-0061 NUT: 8-32" HEX W/SEMS (8 REQ'D.)
42 0017-00031-0052 SOCKET ASSY. W/DIDDE 1M4004 (3 REQ'D.) (SEE PAGE 34) OR
42 0017-00031-0071 SOCKET ASSY. W/DIODE 1N4004 (3 REQ'D.) (SEE PAGE 34)
* NOT PART OF BACK CABINET ASSY. & MUST BE ORDERED SEPARATELY
ITEM PART NO. DESCRIPTION
1 AE47-00015-0000 TARGET: HOT STAMP WHITE
2 A967-00048-0000 COIL AND TUBING ASSEMBLY (2 LUGS)
103E-00002-0015 IN4004GP 400V lA DIODE
3 A967-00012-0000 CORE PLUG & BRKT. ASSY.
4 A967-00066-0000 SWITCH & aIODE ASSY.
A360-00062-0000 SWITCH ASSY.
103E-00002-0005 IN4148 100V 500MA DIODE
5 0010-00274-0189 COMPRESSION SPRING
6 0010-00275-0310 EXTENSION SPRING
7 0011-00006-00XF LINK STUD
8 0017-00042-0428 WASHER: CUPPED NYLON
9 0017 -00100-0117 RING KLI .250 (7 REQ'O.)
10 0020-00202-0000 SWITCH PLATE
11 0360-00118-0000 LI NK (2 RE Q ' O. )
12 0360-00720-00XF PIN: TARGET PIVOT
13 0360-00721-00XF PIN: LINK (2 REQ'O.)
14 0371-00123-29XF SIDE PLATE
15 0967-00105-00XF COIL BRACKET
16 0967-00106-00XF BOTTOM PLATE
17 0967-001 9-00XF LINK
18 0967-00113-00XF BOTTOM PLATE: ADJUSTABLE
~-
19 0967-0 124-00XF END PLATE
20 0967-00144-20XF LATCH PLATE
21 0967-00704-00XF PLUNGER
