BALL SAVER ASSEMBLY: LEFT
PART NO. AE94-00040-0000
1.5
FRONT CABINET ASSEMBLY
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 A365-00334-0000 FRONT RAIL ASSY.
2 AH03-00S00-0000 CABINET ASSY.: HEAVY METAL I
0360-009S3-00XF TEENUT: DOUBLE (4 REQ' D. )
3 A365-0075 ...0000 KEYPAD ASSY.
4 A36S-00327 ..0000 ON/OFF SWITCH & PLATE ASSY. (NOT SHOWN)
0017-00032-0105 SWITCH 2PST 6 AMP {.187" FAST-ON CONNECTORS}
0017 -00104-0111 WASHER: .516" 1.0., 1.2511 0.0. & .062" TH. FLAT NYLON (2 REQ'D.)
0333-00100-0000 SPACER: ON/OFF SWITCH
5 A365-00032-00XF BRKT. & PIN ASSY. - LEFT HAND
AH03-00006-0000 CABINET CABLE W/ASSEMBLIES (INCLUDES ITEMS 6 THRU 9)
6 ' AH03-00007-0000 CABINET CABLE ASSY.
I
I 7 A360-00264-000n I TILT BOARD ASSY.
. A360-000S4-0000 I
-
SWITCH ASSY.: BALL TILT
, 0360-00199-00XF BRKT: BALL TILT
I Q360-00168-0000 BRKT: TILT CONTACT
0360-00170-0000 TILT HANGER
0360-00502-0000 TILT BOARD (WOOD)
0360-00922-00XF WIRE-FORM: PLUMB BOB
8 A365-00316-0100 SWITCH ASSY. W/CAP: PUSH BUTTON (2 REQ I D.)
0360-00071 ..•0000 SWITCH ASSY.: PUSH BUTTON (2 REQ'O.)
9 I 0365-00060-0100 SW ITCH ASSY.: START PUSH-BUTTON (3 REQ'D.)
I' 10 0017-00003-0570 SPEAK8R: 4 OHM 1S WATT 5-1/4" OIA.
I 11 0017-00009-0490 GRILLE: VENT 5-5/8 SQ. IN. I
12 0365-00104-00XF GRILLE: VENT 2-1/411 X 24"
