FRONT CABINET ASSEMBLY
BALL-SAVER ASSY.: LEFT - PARTS LIST
PART NO. AE94-00040-0000
ORDER BY PART NUMBER ONLY
ITEM
PART NO.
DESCRIPTION
1
AE94~OOO43-0000 COIL
&
TUBING ASSY. 2-LUG
2
A360-00038-0000 LEVER-ARM, HUB, CAP
&
TUBING: LEFT
3
A365-00024-0000 CORE PLUG
&
BRACKET ASSY.
4
0017-00042-0413 BEARING: FLIPPER
5
0017-00042-0418
NYLINER:
SNAP-IN; COIL
6
0360-00152-01XF BRACKET: FLIPPER-STOP; LEFT
7
0360-00318-00XF BRACKET: COIL
8
0360-00718-00XF PLUNGER
9
0365-00101-00XF BRACKET: FLIPPER MOUNTING
10
0017-00104-0073 WASHER: .515" I.D., .875" 0 .D.,
&
.013 TH. SPRING STEEL
3.0
1.6
