FRONT CABINET ASSEMBLY
ORDER BY PART NUMBER ONLY
BALL KICKBACK ASSEMBLY - PARTS LISTPART NO. A369-00017-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
13 0365-00115-00XF STAY ARM: PLAYFIELD
14 0365-00116-00XF BRACKET: STAY-ARM
15 0950-00113-00XF HANDLE (PLASTIC): COIN BOX (NOT SHOWN)
16 0950-00903-0000 COIN BOX (PLASTIC)
17 0950-00902-00XF BRKT (PLASTIC): LOCATING COIN BOX (UNDER COIN BOX)
18 M051-00H03-A007 TAG: REGISTER OPTIONS (NOT SHOWN)
19 0967-00115-00XF PLATE: BALL SHOOTER
20 A365-00043-0000 LINE CORD, FILTER, VARISTOR & CONVIENCE OUTLET ASSY.
0017-00003-0114 FILTER: LINE SA 115V
0017-00003-0475 OUTLET CONVENIENCE
0017-00003-0500 LINE CORD 3-CONDUCTOR 18AWG
115E-00001-0001 VARISTOR: METAL-OXIDE 130V
21 A365-00050-00XF BRKT. & PIN ASSY. - RIGHT HAND
22 0017-00007-0019 KEY HOOK: PIN DOOR
23 0950-00114-0000 COVER (PLASTIC): COIN BOX
24 AE94-00061-0000 HIGH VOLTAGE CABLE ASSY.
25 AH03-00300-0000 CATALOG & BAG ASSY. (NOT SHOWN)
OH03-00300-0100 MANUAL: OPERATING
OH03-00300 ..•0200 MANUAL: PARTS
26 0017 ...00003-0513 SPEAKER: 8 OHM 10 WATT 6" x 9"
27 0017-00042-0370 ON/OFF SWITCH COVER (NOT SHOWN)
ITEM PART NO. DESCRIPTION
1 A369-000l8-00XF KICKER-ARM ASSY.
2 OOll-00004-00XF STUD
3 0017-00103-0094 NUT: 8-32 LOCKING
4 0360-00715-00XF PLUNGER
5 0017-00007-0168 PIN: 3/32 X 8 ROLL
6 0360-00316-00XF COIL BRACKET
7 0010-00274-0000 COMPRESSION SPRING
8 0360-00316-00XF COIL BRACKET
9 0017-00104-0073 SPRING WASHER 515-.875-013
10 A967-0004B-0000 COIL (3 LUG) PLUG & BRACKET ASSY.
11 0360-00182-00XF BRACKET: SLINGSHOT KICKER
12 0017-00101-0162 #8-32 X 6 PHIL PAN HD. SCREW (4 REQ'D.)
