8 a
BACK GLASS
GT-40844
WHEN ORDERINGPART. SPECIFY PART 10. AID NAME OF GAME
32 8 32 8832 o
32
o
':{:>OOOO<J::t
c[>OOOOO
cC>OOOOc:::::?
c(>oooao-0 £; fJ 0 0
14"" ,/3,... •
/
/
36
RUBBER PARTS
Dimensions are inside diameters. Numbers in
parentheses indicate Quantity used, if in
excess of one.
A. R-521-2
B. R·521-4
C. R-521-9
D. R-521-1
E. R-406-3
F. R-243
,·1/2" Dia.
2· 1/2" Dia.
5" Dia.
1 "Dia.
Flipper
5/16" Dia.
(3)
(2)
(2)
(2)
(15)
PANE L TOP PARTS
1. Arch rail M·1774
2. Rail Post (2). . . . . . . .. C·907
3. Rail Post Cap (2) C·908
4. Bottom Arch P-5871-68
5. Shooter Gauge P-6359-34
6. Ball Gate (L) A-1475-15
7. Ball Gate (A) .•••... , A-1475-l4
8. Screened Plastics Set A-2890-l35
9. Plastic Guide (4) C-937-5
10. Thumper Cap . . . . . . . . A-371346
11. Thumper Cap A-371347
12. Thumper Cap A-37l3-48
13. Thumper Cap •........ A-3713-49
14. Outhole Kicker ASE-2694-3
15. Target Assy. (red) (4) ASE-2911-3
16_ Target Assy. (yellow) (4) ASE-29l1-21
17. Spinner Assy. . .. . . . . .. ASE-2250-56
18. Sp inner Assv, . . . . . . . . ASE -2250-57
19. R.O.Wire & Brkt ASE-2806
20. R.O. Wire & Brkt ASE-2806-1
21. Ball Guide Wire (2) M-121-56
22. Ball Guide Wire (4) M-12l-32
23. Ball Guide Wire M-12l-24
24. Ball Guide Wire M-121·84
25. Ball Guide Wire M-12l-78
26. Ball Guide Wire M-12l-30
27. Buffer Wire (2) M-121·53
28. Flipper & Shaft Assy. (2) AS-2814·24
29. Free Gate Wire M-1335
30. Push Nut Fastener M·1314-1
31. Outhole Wire Assy ASE-2J306-2l
32. Thumper Body (4) ASE-2222-4
33 .. Protective Angle P-7639
34. Panel (Dom.) CA-1128-168
Panel (Ger.) . _ _ CA-ll28-170
35. Hood _ P-1732
WHEI ORDERING PART,
SPECIFY PART 10.
AID lilliE OFGAME
