BACK GLASS
GT-408-41
(Sold to Germany only)
30
33
G
a
o
o
o
o
) 3
31
BACK GLASS
GT-408-37
0000
000
00
o
.23. Note: For Germany and France top Right Flipper eliminated. Wire
form and Post added as shown below. No. 30 increased to quantity of (8)
I
00
o
RUBBER PARTS
Ojmensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
excess of one.
A. R·243
B. R·521
C. R·52l·1
D.
R·52l·2
E.
R·52l·3
F.
R·521·4
G.
A·52l·5
H. R·521·6
I.
R·406·3
5/6" Dia.
3/4"
Dia.
1" Dia.
H/ 2"
Dia.
2"
Dia.
2·1/2" Dia.
3"
Dia.
3·' /2" Dia.
Flippers"
(3)
(4)
(5)
(4)
PANEL TOP PARTS
1.
Arch Rail. ..•.......
M-1774
2.
Rail Post
C·9D7
3. Rail Post
Cap
C·9DS
4.
Bottom Arch .....•..
P·5871·G7
5. Shooter Gauge
P-6359·33
6. Ball Gate Assy. (R) .••.
A·1475-13
7.
Ball Gate Assy.
(L)
A·1475-12
8.
Ball Gate
&
Wire Assy
ASE·2250-11
9.
Ball Gate & Wire Assy. .. ASE·2250-59
10,
Ball Gate
&
Wire Assy
ASE-2250-25
11.
Ball Gate & Wire Assy
ASE-2250-18
12.
Ball Gate
&
Wire Assy
ASE·2250·60
13. Screened Plastic Set. . . . M·1330·161
14. Spinner Gate Assv, (L) .. ASE·2250-61
15. Thumper Cap Assy. (4) . A·3713·50
16. Outhole Kicker
ASE·2694·3
17 .
Protective Angle. . . . .. P·7639
, 8.
Outhole Wire
ASE-2806·21
19. Rollover Wife . . . . . . .. ASE-280G
20 .. Ball Guide Wire
M·121·53
21.
Target Assy.. . . . . . . .. ASE-2911·3
22. Ball Guide Wire (4) ....
M-121-46
.23. Flipper &. Shaft Assy. (3) ASE-2214-24**
24.
Flipper &. Shaft Assy
ASE-2214·25
25. Ball Guide Wire
M-121·18
26.
Ball Guide Wire
M-121-47
27. Ball Guide Wire •......
M-121-30
28. Ball Guide Wire
M-121--83
29. Rollover Button
(4) . . ..
C-9DO
30. Mini·Post Assy. (7)
AS-2836-1***
3t.
Hood
P-1732
32. Panel
CA-1226-1
33. Thumper Body (4)
ASE-2222-4
34. Post . .. . . . . . . . . . . .. C-9S1-7
35. Ball Guide Wire
M-121-29
Notels):
.• '" 2
on German and French Models
**
=
2
on German and French Models
•.**
=
8
on German and French Models
Post installed into vacant FIi pper shaft th
ru
hole.
WHEN
ORDERING
PART. SPECIFY PART 10. AND
IIlME
OF
GAME
~
WHEN ORDERING PART. SPECIFY PART
NO. AID NAME
OF GAME
