34
KISS o SWITCH ASSEMBLY IDENTIFICATION NUMBERS
o INDICATES SWITCH ASSEMBLY
IDENTIFICATION NUMBERS.
NOTE: CABINET: 07,16
DOOR: 06,09, 10,
11, 16
o INDICATES SOLENOID
IDENTIFICATION NUMBERS.
NOTE; DOOR: 11
BACKBOX: 12
CABINET: 02
6. INDICATES ASSEMBLY
IDENTIFICATION NUMBERS
1. Drop Target 0 (Bottom) ..•........... ASW·A '·168
2. Drop Target C ASW·A1·168
3. Drop Target B ........•........... ASW-A1·168
4. Drop Target A (Top) ASW·A1·168
5. Lite-A. Li ne 5,000 Rollover ASW·A '·155
6.
7. Tilt ..............•........... ASW-Al·145
8. Outhole. . . . . . . . . . ...•........•.. ASW-.A 1-143
9.
10.
11.
12. 'D'Target ...........•........... ASW·A10-48
13. 'C'Target ' .....•...•....... ASW A10-48
14. 'B'Target ..•.................•.. A.SW-A10-48
15. 'A'Target ASW-A10-48
16.
17. Lower 'S' Target. . . . . . . . . .. . . . . . .... ASW-A 10-48
18. Upper'S' Target ..................• ASW-A1048
19. 'I' Target ................•....... ASW·A10-48
20. 'K'Target ASW-A10-48
o
21. Outer'S' Rollover ................•. ASW·A1-155
22. Inner'S' Rollover •.........•.....•. ASW·A '-155
23. ' I 'Rollover ..............•.....•. ASW-A1-155
24. 'K' Rollover ....................•. ASW·A1·165
25. Drop Target and 2 Rebs .••....•....... ASW·A 10-47
26. Right Flip/Feed Lane ...•....•.....• ASW-Al0-155
27. Left Flip/Feed Lane .....•..•.•.... ASW-A10-155
28. Right Flipper Assy. Switch ASW-A20-23
29. Left Flipper Assy. Switch .....•..... J • ASW·A20·23
30. Right Spinner ...................•.• ASW·A1-151
31. Left Sp inner .•..•....•..•.•....••. ASW·A 1-151
32.
33. Right Outlane ...•....•........••.. ASW·A 1-155
34. Left Outlane ... _ .... _ .........•.. ASW-Al-155
35. Right Slingshot ..•.........•....••. ASW·Al0-47
36. Left Slingshot ...•....•....•....... ASW-A10-47
37. Bottom Th umper Bumper ASW·A 110-5
38. Top Thumper Bumper .••.......••.•. ASW-A110-5
39. Righ t Th umper Bumper ••....•....•.. ASW-A 110-5
40. Left Thumper Bumper ASW~A 110·5
o SOLENOID AND COIL IDENTIFICATION NUMBERS
1. Outhole Kicker AN·26·1200
2. Knocker AR-26-1200
3. Drop Target Reset N0-26-1900
4. Left Thumper Bumper AN-26-1200
5. Right Thumper Bumper ......•....... AN-26-1200
6 . Bottom Thumper Bu mper. . . . . • • . . • . . • AN-26-1200
7. Top Thumper Bumper .•.....•.....•. AN-26-1200
8. Left Slingshot ...••...•..•.•.....•. AN-2S-1200
9. Right Slingshot ... _ _ ....•..... _ . AN-26-1200
10. Right Bottom Gate GA-34-4000
11. Coin Lockout (Door) .•......•....... FO·3S-7000
12. FIipper(s) .••....••.•.•..•.• AO·25-500/34-4500
6. ASSEMBLY IDENTIFICATION NUMBERS
PANEL BOTTOM PARTS
1. Top Thumper .•..•............. _. ASE-1567-13
2. Left Thumper : ASE-1567-13
3. Right Thumper .................•. ASE·1567-13
4 . Bottom Thumper .......•.....•... ASE-1567-13
5. Drop Target _. ASE-2795-47
WHEN ORDERING PART,
SPECIFY PART NO.
AND NAME OF GAME
6. Left Slingshot .........•....•...... ASE-2593-4
7. Right Slingshot .........•........... ASE-2593-4
8. Left Flipper .....•............... ASE-1587-101
9. Right Flipper ....•............... ASE·1587-102
10. Free Ball Gate ........•.........• ASE-2308-22
For assembly breakdown, see back of book.
WHEII ORDERI. PART. SPECIFY PART NO. AND lAME OFGAME
35
