Jet Bumper Assembly
pIn 8-9414
Item
Part No.
Description
1 A-4754 Bumper Ring Assy
2 03-6009-A5 Bumper Base-Wht
3 03-6035-5 Bumper Wafer-Wht
4 03-7443-5 Bumper Body-Wht
5 10-7
Spring-Jet Bumper
6 A-11199 Socket
&
Bulb Assy
7 03-8254-9 Bumper Cap
Jet Bumper Coil Assembly
pIn 8-9415-1
Item
Part No.
Description
1
2
3
4
5
6
7
8
9
B-7417
01-1747
01-5492
01-5493
02-3406-1
10-326
AE-23-800
4006·01017-04
03-7066
Bracket
&
Stop Assy
Coil Retaining Bracket
Armature Link. Steel
Armature Link. Bakelite
Coil Plunger
Armature Spring
Coil Assembly
Mach. Screw. 6-32
x
1/4
Coil Tubing
JET BUMPER ASSEMBLY
JET BUMPER COIL ASSEMBLY
Knocker Assembly
pin
B-10686-1
Item
Part No.
Description
3
1
A-5387
Coil Plunger Assembly
a) 02-2653
Coil Plunger
b) 03-6013
Bell Arm Ext.
2 B-7409-2
Mtg. Bracket Assembly
3 AE·23·800
Coil Sub-Assembly
4 01-8·508·T
Coil Retaining Bracket
5 23·6420
Rubber Grommet
6 4008-01017 ·06 Mach. Screw
J
8/32 x
3/8
7 H-11835
Knocker Cable
8 03-7067-5
Coil Tubing
Jet Bumper
&
Knocker 2·17
