Top Ramp Gate
pIn 8·13380
Item Part No.
1
01-9527
2
A-12958
3 4006-01003-05
4
A-13381
5
10-120
6 SM2-35-4000
7 4700-00089-00
8 4701-00003-00
9 4008-01021-07
Description
Mounting Bracket
Frame & Eyelet Assembly
M.S. 6-32 x .31 P-PHS
BIG
Armature Assembly
Compression Spring
Coil AssemblywI Diode
.172 x 44 Flat Washer
#8 Split Lock Washer
#8-32 x .44 P-RH BR
Multi-ball Kicker Assembly
(Ball Locker)
pIn
C-13386
Item Part No.
Decsrlptlon
1
A-13270
Armature Assembly
2
AE-23-800 Coil Sub-assembly
3
01-8-508-T Solenoid Bracket
4
01-8918
Coil Mounting Bracket
5
10-135
Solenoid Spring
6
03-7067-5 Coil Tubing
7
23-6420
Rubber Grommet
8 4008-01017-04 M.S. 8-32 x .25L P-RH-S
Ball Shooter
pIn 8·12445·1
Item Part No.
1
2
3
4
5
6
7
03-7357
10-149
20-9253-7
21-6645-1
10-148-1
20-8718-1
23-6327
Description
Sleeve
Rod Spring
Rod Assembly
Ball Shooter Housing
Shooter Spring
"C" Ring
Shooter Tip
Top Ramp Gate, Ball Shooter
2.1
8 Multl·ball
Kicker (Ball Locker)
5
