GAME ADJUSTMENTS
A. Playfield Panel Post Adjustments:
Posts that control left and right outlane opening on panel can be moved to make access to
outlanes easier or harder for ball to enter. See Figure II.
Easier entry will decrease playing time and scoring (conservative).
Harder entry will increase playing time and scoring (liberal).
e,
Back Box Game Adjustments:
Each game has thirty-two switches located on A4, the MPU module, located in the back box,
that allow play to be customized to the location. See Figure III. Credits per coin, maximum
credits, credit display, balls per game, match feature, high game feature, special award and
melody are selectable by means of the switches, The switches are contained in four-sixteen
lead packages numbered 51-8, 59-16, 517-24 and 525-32 for easy identification. The "ON"
toggle position is marked on the assembly. Turn off power before making adjustments.
Credits/Coin Adjustments:
The credits per coin are selectable by means of 517-520 for coin chute
#
2. The switch settings
and resultant credits/coin are as follows:
S20 S19 518 $17
OFF OFF OFF OFF
OFF OFF OFF ON
OFF OFF ON OFF
OFF OFF ON ON
OFF ON OFF OFF
OFF ON OFF ON
OFF ON ON OFF
OFF ON ON ON
ON OFF OFF OFF
ON OFF OFF ON
ON OFF ON OFF
ON OFF ON ON
ON ON OFF OFF
ON ON OFF ON
ON ON ON OFF
ON ON ON ON
The credits given per coin are selectable by means of switches 1-5 incl., for coin chute #1 and
switches 9-13 incl., for coin chute #3. Thirty-one different credit ratios are available for each
coin chute. The switch settings and resultant credits/coin are listed below.
CREDITS/COIN ADJUSTMENTS
COIN CHUTE
#
I (HINGE SIDE)
OR #3
'No Crertns Will secono coin
IS
dropped
. 'One Crf'dlt for ~irS1
<;fllr 'l
Two Credit'S. for secono
COin prOVided HICi.l
no
scor inq occueed Of.>lwecn
1
st and 2 nd
COl
n d raps If sco ring
Of:C LJ
r~~d
sst-end
CO II1
qivcs
(Hl e
credit
Credits/Coin
Same as Coin Chute #1 Settings
1/1 Coin
211
Coin
3/1 Coin
4/1
Coin
5/1
Coin
611
Coin
7/1
Coin
8/1 Coin
9/1
Coin
1011
Coin
11/1
Coin
12/1 COin
13/1 Coin
1411
Coin
1511
Coin
SWITCHES
CREDITS/COIN
5
4
3
2
1
13 12 11 10
9
OFF OFF OFF OFF OFF 3/2 COINS·'
OFF OFF OFF OFF ON 3/2 COINS"
OFF OFF OFF ON OFF l i COIN
OFF OFF OFF ON ON 1/2 COINS'
OFF OFF ON OFF OFF
2iCOIN
OFF OFF ON OFF ON
2i2
COINS'
OFF OFF ON ON OFF 3/COIN
OFF OFF ON ON ON 3/2 COINS'
OFF ON OFF OFF OFF 4.'COIN
OFF ON OFF OFF ON
4/2
COINS'
OFF ON OFF ON OFF SiCOIN
OFF ON OFF ON ON 5/2 COINS'
OFF ON ON OFF OFF 6/COIN
OFF
ON
ON OFF ON 6.,'2 COINS'
OFF ON ON ON OFF 7iCOIN
OFF ON ON ON ON
r.:
COINS'
ON OFF OFF OFF OFF 8/COIN
ON OFF OFF OFF ON
8 i2
COINS·
ON OFF OFF ON OFF 9 i COIN
ON OFF OFF ON ON 9/2 COINS'
ON OFF ON OFF OFF lQiCOIN
ON OFF ON OFF ON 10/2 COINS'
ON OFF ON ON OFF 11/COIN
ON OFF ON ON ON 11,2COINS'
ON ON OFF OFF OFF 12'COIN
ON ON OFF OFF ON 12,2COINS'
ON ON OFF ON OFF 13iCOIN
ON ON OFF ON ON 13/2 COINS'
ON ON ON OFF OFF 14iCOIN
ON ON ON OFF ON 14/2 COINS'
ON ON ON ON OFF 15/ COIN
ON ON ON ON ON 15/2 COINS'
